Northtech NT-12L Left Hand 12'' Table Saw
orCall +1 (607) 678-4374
Description
The NT-12L Table Saws employs a rugged steel cabinet and extended steel top for decades of dependable use. The le tilting blade adjustment is easily accessible on the front of the machine with visual angle scale. Optional 7.5HP or 5HP motor provides a 4″ cut depth at 90 degrees and almost 3″ at 45 degrees. Optional side slide table runs along lineal rail for precision panel cutting.
Specifications
| Manufacturer | Northtech |
| Model | NT-12L |
| Condition | New |
| Stock Number | NT-12L |
| MAIN MOTOR HP | 7.5 HP |
| VOLTAGE, FREQUENCY | 230/460 Volt |
| PHASE | 3 Phase |
| AMP REQUIREMENT | 20/10 Amps |
| ELEVATION STYLE | Manual Wheel Adjustment |
| ELEVATION SYSTEM | Worm Gear |
| TOTAL MACHINE HP | 7.5 HP |
| APPROVED ELECTRICAL PARTS | CE Approved Parts |
| DUAL VOLTAGE MOTORS | 230/460 Volt |
| CONTROL VOLTAGE | 230/460 Volt Line Voltage |
| PASS-LINE | 34-1/8'' |
| CUTTING ENVELOPE | 4'' x 51'' with Fence |
| MAX. WORKING WIDTH | 51'' |
| MAX. WORKING THICKNESS | 4'' |
| ABLE TO CUT ANGLE | Yes |
| ARBOR RPM | 4150 RPM |
| BLADE SIZE | 12'' Sawblade |
| NO. OF TEETH ON BLADE | 80 Tooth |
| TOOTH SPACING | .435'' |
| BLADE KERF | 2.5 MM |
| VERTICAL TRAVEL | 4'' On Sawblade |
| DUST COLLECTION REQUIREMENT | 436 CFM @ Extraction Points |
| DUST PORT SIZE OUTLET | (1) 4'' Port |
| ARBOR DIAMETER | 1'' |
| SAFETY FEATURE | Clearview Overhead Blade Guard |
| OPERATION STYLE | Manual |
| FENCE TYPE | Adjustable |
| FENCE DIMENSIONS | 2-1/2'' x 39-3/4'' |
| TILT-ABLE | 45-90 Degrees |
| FRAME CONSTRUCTION | Steel |
| WORKTABLE DIMENSIONS | 30'' x 48'' |
| TABLE CONSTRUCTION MATERIAL | Machined Cast |
| MEASURING METHOD | Ruler On Fence |
| DECIBEL RATING | 78 dB |
| NET WEIGHT | 542 Lbs. |
| GROSS WEIGHT | 666 Lbs. |
| MACHINE DIMENSIONS | 84-3/4'' x 45'' x 40'' |
| PACKAGING DIMENSIONS | 40 x 48 x 86 |
