Timbertech GT635 25'' Double Surface Planer Showroom Machine

Timbertech GT635 25'' Double Surface Planer Showroom Machine

$30,000 (USD)

Regular Price $33,000

Location:Dundee, NY

Available quantity:1

Description

Spring loaded conveyor pin system ensures material is passed over the bottom cutterhead to resulting in a flat and uniform board prior to planing to thickness on the top head

Spiral insert knife cutterheads with two-sided solid carbide knives produce a smooth finish with increased stock removal capacity and extremely quiet operation

Heavy-duty cast-iron machine body and table for vibration free cutting

Specifications

ManufacturerTimbertech
ModelGT635
ConditionUsed
Stock NumberS1112
Max working width635mm(25”)
Max working thickness200mm(8”)
Min working thickness0.39''
Min working length12.2''
Knife shaft diameter5000rpm
Variable frequency feed speed8-18m/min
Dust Port Diameter5”(Upper)/6”(Lower)
Top Head HP25HP
Bottom Head HP20HP
Feed motor3 HP
Table elevation motor1/2 HP
WORKTABLE DIMENSIONS27”x102”
Knife dimensions15 x 15 x 2.5
Machine dimensions (LxWxH)105″ x 45.1″ x 67″
Net Weight6922
Gross Weight7650
